Panasonic Concealed Door Closer CY-950
Body size (mm): 230×57×32
Maximum opening angle (degrees): 120
Product description: C series concealed type, maximum door width 950mm, load-bearing 60KG, yes Impact relief valve, with explosion-proof device, silver appearance, slide rail arm, can be positioned.
●Standard equipment ○Without this device
Strength |
Maximum door width |
Door weight |
|
#2 |
850mm |
40kg |
○ |
#3 |
950mm |
60kg |
● |
|
1000mm |
70kg |
○ |
|
1050mm |
75kg |
○ |
#4 |
1100mm |
80kg |
○ |
#5 |
1250mm |
100kg |
○ |
Body size |
long |
230 |
high |
57 |
width |
32 |
Arm |
Standard arm |
○ |
Track arm |
● |
Rack rotation |
● |
Arm end strength adjustment plate |
○ |
Maximum opening angle |
120° |
Maximum door width (mm) |
950 |
Spring force regulator |
○ |
Displacement force adjustment |
○ |
Door closing speed regulator |
● |
Locking speed regulator |
● |
Explosion-proof device |
● |
Arm type |
Slide rail arm |
Positioning means |
Track arm with positioning |
● |
Standard stop arm |
○ |
Inside stop |
|
○ |
Back cushion |
Power adjustable |
○ |
Shared left and right doors |
● |
Installation method |
regular |
○ |
Flip |
○ |
parallel |
○ |
Slotting |
● |
Exposed or hidden |
hide |
|
